Magnetic Stirrers Plus

| Laboratory Products | Magnetic Stirrers Plus

REMI presents the next generation of magnetic stirrers with new stir technology. These are available in both hotplate
& without hotplate versions.

Salient Features
  • Speeds range 150 – 1500 rpm
  • Stainless Steel Hot Plate model for temperatures up to 340°C
  • Ceramic Hot Plate model for temperatures up to 550°C (10 MLH Plus)
  • Easy-to-read backlit LCD for display of set & actual parameters
  • Monitoring of set & actual temperature / speed
  • High accuracy of temperature control with embedded dual sensors
  • Advanced Stirrers with microprocessor technology
  • Constant speed even with change of load / Voltage
  • Maintenance free brushless motor
  • Scratch proof & excellent chemical resistance
  • External temperature probe (PT-1000) for control of fluid temperature
  • Last parameter recall, ideal for repetitive processes
  • Unique safety temperature control system
  • Settable safe temperature limit to avoid overheating
  • Residual Temperature warning when unit is switched off for operator safety
Technical Specifications
Model
Power (W) 550 1050 50
Max. stirring quantity (Water)(Liters) 5 10 20
Stirring Paddle (PTFE coated) Q-19A (9 x 35mm) Q-20A (13 x 50mm) Q-20A (13 x 50mm)
Motor rating input (W) 18 18 18
Motor rating output (W) 10 10 10
Speed range (rpm) 150-1500 150-1500 150-1500
Speed / Temperature display LCD LCD LCD
Speed display resolution (rpm) 1 1 1
Top Plate Material Stainless Steel Cereamic Glas Stainless Stee
Dimension of Top Plate (mm) 157 184 x 184 300 x 350
Heating power (W) 500 1000
Temperature Range Up to 340°C Up to 550°C
Control accuracy of heating temperature 1°C 1°C
Residual Heating Warning Alarm Above 50°C Above 50°C
Control accuracy of heating temperature with PT-1000 0.2°C 0.2°C
External Temperature sensor PT-1000 PT-1000
Dimensions (WxDxH) (mm) 342 x 210 x 115 360 x 215 x 112 300 x 350 x 100
Protection class acc. to DIN EN60529 IP 21

Supply: 220-240 Volts, 50 Hz Single Phase

Salient Features
  • Large LCD screen
  • Microprocessor controller
  • Stepless speed regulation
  • Aluminum alloy working plate
  • Over-temp alarm system, auto switch off when 380°C
  • Caution indication light: auto switch on when working plate temperature is over 50°

Technical Specifications
Model
Stirring capacity (H O) (Liters 15
Speed range(rpm) 200 – 1800
Heating power (Max. W) 750
Input power (Max. W) 800
Working plate temp range (°C) RT+5~380°C
Stirring Paddle (PTFE coated) Q-20A (13 x 50mm)
Plate dimension (mm) 180X180
Exterior dimension (W x D x H) (mm) 210x330x130
Weight (KG) 4.5

Supply: 220-240 Volts, 50 Hz Single Phase
